Hotel and Hospitality Range Selector
A range of made-to-order doorsets for hotels and hospitality
Our step-by-step guide to specifying doorsets and ironmongery will help guide you through the specification process.
Once you are happy with your selections, please e-mail your requirements to sales@ahmarra.co.uk for a full quotation or contact our experienced sales team on 02392 389 076 who will be able to discuss your project requirements and offer further advice.
Experienced Specification Team We work closely with architects to help you achieve the correct specification for your project.
1 : Doorsets
Select the most appropriate door type for each structural opening. Ahmarra can also accommodate if a custom configuration is necessary.
Guest Rooms +
Public Spaces +
Guest Facilities +
Toilets & Washrooms +
Back of House +
Store Rooms & Utilities +
Multi-use +
Pocket Sliding Doors +
Doorset 01
Guest Bedroom
Doorset 01
Guest Bedroom
Single Door, Nightlatch, Card/FOB, Lever Handle, Room Number, FDKS
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm |
| Core Width: | 54 mm |
| Structural Opening Width: | 1005 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 1
| Quantity | Component | Fitted |
|---|---|---|
| 3 | Hinges | Yes |
| 1 | Concealed Closer | No |
| 1 | Access control lock | No |
| 1 | Lever Handle set | No |
| 1 | Room number | No |
| 1 | Door Viewer | Yes |
| 1 | FDKS sign | Fr Only |
Doorset 02
Guest Bathroom
Doorset 02
Guest Bathroom
Single Door, Bathroom Lock, Open into Room
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1005 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 6
| Quantity | Component | Fitted |
|---|---|---|
| 3 | Hinges | Yes |
| 1 | Bathroom Lock | Yes |
| 1 | Bathroom turn/release | No |
| 1 | Lever Handle set | No |
| 1 | Pivot set | No |
| 1 | Privacy seal | No |
| 1 | Emergency release doorstop | No |
Doorset 02-FV (Full Vision Panel)
Guest Bathroom
Doorset 02-FV (Full Vision Panel)
Guest Bathroom
Single Door, Bathroom, Open into Room, Full Privacy Panel
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm |
| Core Width: | 54 mm |
| Structural Opening Width: | 1005 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 6
| Quantity | Component | Fitted |
|---|---|---|
| 3 | Hinges | Yes |
| 1 | Bathroom Lock | Yes |
| 1 | Bathroom Turn/Release | Yes |
| 1 | Lever Handle Set | No |
| 1 | Pivot Set | No |
| 1 | Privacy Seal | No |
| 1 | Emergency Release Doorstop | No |
Doorset 03
Guest Bedroom with Interconnecting Suite
Doorset 03
Guest Bedroom with Interconnecting Suite
Back to Back Single Doors, Sashlock, FDKL, Lever Handle (Pack 2)
Back to Back Single Doors, Sashlock, FDKL, Cylinder Pull, (Pack 3)
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1005 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 2
| Quantity | Component | Fitted |
|---|---|---|
| 6 | Hinges | Yes |
| 2 | Sashlock | Yes |
| 2 | Lever Handle Set | No |
| 4 | Escutcheon | No |
| 2 | Half Spindle | No |
| 2 | Half Cylinder | No |
| 2 | FDKL Sign | Fr Only |
Pack 3
| Quantity | Component | Fitted |
|---|---|---|
| 6 | Hinges | Yes |
| 2 | Sashlock | Yes |
| 2 | Half Cylinder | No |
| 2 | Cylinder Pull | No |
| 2 | Escutcheon | No |
| 2 | FDKL Sign | Fr Only |
Doorset 04
Guest Bedroom Suite Double Doors
Doorset 04
Guest Bedroom Suite Double Doors
Double doors, Free Access, Lever Handle, Full Vision Panel
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm + 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1934 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 4
| Quantity | Component | Fitted |
|---|---|---|
| 6 | Hinges | Yes |
| 1 | Latch | Yes |
| 1 | Lever Handle Set | Yes |
| 2 | Flush Bolts | Yes |
| 1 | Easy Clean Floor Socket | Yes |
| 2 | Full Vision Panel | Yes |
Doorset 05
Accessible Guest Bedroom
Doorset 05
Accessible Guest Bedroom
Single Door, Lever Handle, Nightlatch, Access Control
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm |
| Core Width: | 54 mm |
| Stuctural Opening Width: | 1005 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 5
| Quantity | Component | Fitted |
|---|---|---|
| 3 | Hinges | Yes |
| 1 | Concealed Closer | No |
| 1 | Access Control Lock | No |
| 1 | Lever Handle Lock | No |
| 2 | Escutcheon | No |
| 1 | Room Number | No |
| 2 | Door Viewer | Yes |
Doorset 08
Accessible Guest Bathroom
Doorset 08
Accessible Guest Bathroom
Unequal Double Doors, Bathroom Lock, Lever Handle
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm + 463mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1471 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 9
| Quantity | Component | Fitted |
|---|---|---|
| 3 | Hinges | Yes |
| 1 | Bathroom Lock | Yes |
| 1 | Lever Handle Set | No |
| 1 | Bathroom Turn/Release | No |
| 1 | Pin Support Bracket | No |
| 1 | Rollan 80 Track Set | Yes |
| 1 | Top Pivot Pin | Yes |
| 1 | Double Action Pivot Set | Yes |
Doorset 09
Accessible Guest Bathroom (Single Action Emergency Release Stop)
Doorset 09
Accessible Guest Bathroom (Single Action Emergency Release Stop)
Single Door, Full Privacy Panel, Bathroom Lock, Disabled Guest room door, Lever Handle
This door is single action with an emergency release stop
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1005 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 6
| Quantity | Component | Fitted |
|---|---|---|
| 1 | Bathroom Lock | Yes |
| 1 | Bathroom Turn/Release | Yes |
| 1 | Accessible Toilet Sign | No |
| 1 | Lever Handle Set | No |
| 1 | Pivot | No |
| 1 | Privacy Seal | No |
| 1 | Emergency Release Stop | Yes |
Doorset 10
Accessible Guest Bathroom
Doorset 10
Accessible Guest Bathroom
Single, Emergency Release, Pivot Hung, Disabled Guest room, Lever Handle
This door is on a pivot hinge
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm |
| Core Width: | 44 mm |
| Stuctural Opening Width: | 1005 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 7
| Quantity | Component | Fitted |
|---|---|---|
| 1 | Bathroom Lock | Yes |
| 1 | Lever Handle Set | No |
| 1 | Bathroom Turn/Release | No |
| 1 | Accsessible Toilet Sign | No |
| 1 | Pivot Set | Yes |
| 1 | Emergency Release Stop | Yes |
Doorset 11
Accessible Guest Sliding Bathroom Door
Doorset 11
Accessible Guest Sliding Bathroom Door
Accessible Pocket Sliding bathroom door
Locking, Opens Flush with Lining
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1832 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2137 mm |
Ironmongery Items
| Quantity | Component | Fitted |
|---|---|---|
| 1 | Pocket Doors System | No |
| 1 | Turn and Release Fulsh Pull Kit | No |
| 1 | Finger Pull | No |
| 1 | Sliding Door Lock & Keep | Yes |
Doorset 12
Corridor, Stairwell, BOH, FOH
Doorset 12
Corridor, Stairwell, BOH, FOH
Single Door, Push/Pull, FDKS
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1005 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 10
| Quantity | Component | Fitted |
|---|---|---|
| 3 | Hinges | Yes |
| 1 | Closer | No |
| 1 | Pull Handle | No |
| 1 | Push Plate | No |
| 2 | Kick Plates | Yes |
| 2 | FDKS sign | Fr Only |
| 1 | Deadlock | Yes |
| 1 | Cylinder | No |
Doorset 12-HO (Hold Open)
Corridor, Stairwell, BOH, FOH
Doorset 12-HO (Hold Open)
Corridor, Stairwell, BOH, FOH
Single Door, Push/Pull, AFDKC, Hold Open
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1005 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
| Quantity | Component | Fitted |
|---|---|---|
| 3 | Hinges | Yes |
| 1 | Hold Open | No |
| 1 | Pull Handle | No |
| 1 | Push Plate | No |
| 2 | Kick Plates | Yes |
| 2 | AFDKC Sign | Fr Only |
| 1 | Deadlock | Yes |
| 1 | Cylinder | Yes |
Doorset 13
Corridor, Stairwell, BOH, FOH
Doorset 13
Corridor, Stairwell, BOH, FOH
Double Door, Push/Pull, FDKS
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm + 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1934 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 11
| Quantity | Component | Fitted |
|---|---|---|
| 6 | Hinges | Yes |
| 2 | Closer | No |
| 2 | Pull Handle | No |
| 2 | Push Plate | No |
| 4 | Kick Plates | Yes |
| 4 | FDKS Sign | Fr Only |
| 1 | Deadlock | Yes |
| 1 | Cylinder | No |
Doorset 13-HO (Hold Open)
Corridor, Stairwell, BOH, FOH
Doorset 13-HO (Hold Open)
Corridor, Stairwell, BOH, FOH
Double Door, Push/Pull, AFDKC, Hold Open
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm + 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1934 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 13
| Quantity | Component | Fitted |
|---|---|---|
| 6 | Hinges | Yes |
| 2 | Hold Open Closer | No |
| 2 | Pull Handle | No |
| 2 | Push Plate | No |
| 4 | Kick Plates | Yes |
| 4 | AFDKC Sign | Fr Only |
| 1 | Deadlock | Yes |
| 1 | Cylinder | No |
Doorset 14
Corridor, Stairwell, BOH, FOH
Doorset 14
Corridor, Stairwell, BOH, FOH
Single door, Push/pull, FDKS
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1005 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 14
| Quantity | Component | Fitted |
|---|---|---|
| 3 | Hinges | Yes |
| 1 | Closer | No |
| 1 | Deadlock | Yes |
| 1 | Cylinder | No |
| 2 | Escutcheon | Yes |
| 1 | Pull Handle | No |
| 1 | Push Plate | No |
| 2 | Kick Plates | Yes |
| 2 | FDKS Sign | Fr Only |
Doorset 15
Corridor, Stairwell, BOH, FOH
Doorset 15
Corridor, Stairwell, BOH, FOH
Double door, Push/pull, FDKS, Deadlock
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm + 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1934 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 15
| Quantity | Component | Fitted |
|---|---|---|
| 6 | Hinges | Yes |
| 2 | Closer | No |
| 1 | Deadlock | Yes |
| 1 | Cylinder | No |
| 2 | Escutcheon | Yes |
| 2 | Pull Handle | No |
| 2 | Push Plate | No |
| 4 | Kick Plates | Yes |
| 4 | FDKS Sign | Fr Only |
| 2 | Flush Bolt | Yes |
| 1 | Easy Clean Floor Socket | No |
Doorset 15-HO (Hold Open)
Corridor, Stairwell, BOH, FOH
Doorset 15-HO (Hold Open)
Corridor, Stairwell, BOH, FOH
Double door Push/pull, FDKS, Hold Open CLoser
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm + 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1934 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 17
| Quantity | Component | Fitted |
|---|---|---|
| 6 | Hinges | Yes |
| 2 | Hold Open Closer | No |
| 1 | Deadlock | Yes |
| 1 | Cylinder | No |
| 2 | Escutcheon | Yes |
| 2 | Pull Handle | No |
| 2 | Push Plate | No |
| 4 | Kick Plates | Yes |
| 4 | AFDKC Sign | Fr Only |
| 2 | Flush Bolt | Yes |
| 1 | Easy Clean Floor Socket | No |
Doorset 16
Spa, Pool, Gym, Conference Room
Doorset 16
Spa, Pool, Gym, Conference Room
Single Door, Push/Pull, Access Control, Deadlock
Technical Details
| Door Core: | Severecore™ |
|---|---|
| Door Width (recommended): | 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1005 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 18
| Quantity | Component | Fitted |
|---|---|---|
| 3 | Hinges | Yes |
| 1 | Closer | No |
| 1 | Access Control | No |
| 1 | Cylinder | No |
| 2 | Escutcheon | Yes |
| 2 | Pull Handle | No |
| 2 | Push Plates | No |
| 2 | Kick Plates | Yes |
| 2 | FDKS Sign | Fr Only |
Doorset 17
Spa, Pool, Gym, Conference Room
Doorset 17
Spa, Pool, Gym, Conference Room
Double door, Access control, Push/Pull
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm + 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1934 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
| Quantity | Component | Fitted |
|---|---|---|
| 6 | Hinges | Yes |
| 2 | Closer | No |
| 1 | Access Control | No |
| 1 | Cylinder | No |
| 2 | Escutcheon | Yes |
| 2 | Pull Handle | No |
| 2 | Push Plates | No |
| 4 | Kick Plates | Yes |
| 4 | FDKS Sign | Fr Only |
| 2 | Flush Bolts | Yes |
| 1 | Easy Clean Floor Socket | No |
Doorset 18 WC
Male, Female, Shower, Changing Room
Doorset 18 WC
Male, Female, Shower, Changing Room
Single Door, Lever, Toilet, Bathroom Lock
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (recommended): | 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1005 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 18
| Quantity | Component | Fitted |
|---|---|---|
| 3 | Hinges | Yes |
| 1 | Bathroom Lock | Yes |
| 1 | Lever Handle Set | No |
| 1 | Bathroom Turn/Release | No |
| 1 | Toilet Symbol | No |
| 1 | Kick Plate | Yes |
| 1 | FDKS Sign | Fr Only |
Doorset 19 WC
Male, Female, Accessible, Shower, Changing Room
Doorset 19 WC
Male, Female, Accessible, Shower, Changing Room
Unequal Double Doors, Bathroom Lock, Lever Handle, Accessible
Technical Details
| Door Core: | Severecore™ |
|---|---|
| Door Width (recommended): | 926 mm + 463mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1471 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 9.1
| Quantity | Component | Fitted |
|---|---|---|
| 3 | Hinges | Yes |
| 1 | Bathroom Lock | Yes |
| 1 | Lever Handle Set | Yes |
| 1 | Bathroom Turn/Release | Yes |
| 1 | Disabled Toilet Sign | Yes |
| 1 | Pin Support Bracket | Yes |
| 1 | Rollan 80 Track Set | Yes |
| 1 | Top Pivot Pin | Yes |
| 1 | Double Action Pivot Set | Yes |
| 2 | Kick Plates | Yes |
Doorset 21 WC
Male, Female, Accessible, Shower, Changing Room
Doorset 21 WC
Male, Female, Accessible, Shower, Changing Room
Single Door, Pivot Hung, Emergency release, Accessible , Bathroom Lock
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1005 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 7.1
| Quantity | Component | Fitted |
|---|---|---|
| 1 | Bathroom Lock | Yes |
| 1 | Bathroom Turn/Release | Yes |
| 1 | Accessible Toilet Symbol | No |
| 1 | Lever Handle Set | No |
| 1 | Pivot Set | No |
| 1 | Privacy Seal | No |
| 1 | Emergency Release Doorstop | Yes |
| 1 | Kick Plate | Yes |
Doorset 22 WC
Male, Female, Accessible, Shower, Changing Room
Doorset 22 WC
Male, Female, Accessible, Shower, Changing Room
Accessible Silding WC, Locking, Opens Flush with Lining
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1832 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2137 mm |
Ironmongery Items
Pack 4.1
| Quantity | Component | Fitted |
|---|---|---|
| 1 | Pocket Door System | No |
| 1 | Turn & Release Fulsh Pull Kit | No |
| 1 | Finger Pull | No |
| 1 | Sliding Door Lock & Keep | No |
| 1 | Accessible WC Sign | No |
Doorset 24 WC
Male, Female, Accessible, Shower, Changing Room
Doorset 24 WC
Male, Female, Accessible, Shower, Changing Room
Single Door, Pivot Hung, Emergency Release, Multi Guest WC
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1005 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 33
| Quantity | Component | Fitted |
|---|---|---|
| 3 | Hinges | Yes |
| 1 | Closer | No |
| 1 | Pull Handle | No |
| 1 | Bathroom Turn/Release | No |
| 1 | Push Plate | No |
| 2 | Kick Plates | Yes |
| 2 | FDKS Sign | Fr Only |
| 1 | Toilet Symbol | No |
| 1 | Air Transfer Grille | Yes |
Doorset 25-PH (Port Hole)
Kitchen, Laundry, Housekeeping
Doorset 25-PH (Port Hole)
Kitchen, Laundry, Housekeeping
Single Door, Double Action, FDKS, Porthole Vision Panel
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm |
| Core Width: | 54 mm |
| Structural Opening Width: | 1005 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 20
| Quantity | Component | Fitted |
|---|---|---|
| 1 | Double Action Floor Spring Set | No |
| 1 | Pull Handle | No |
| 1 | Push Plates | Yes |
| 2 | Kick Plates | No |
| 2 | FDKS Sign | Fr Only |
Doorset 25-SV (Square Vision Panel)
Kitchen, Laundry, Housekeeping
Doorset 25-SV (Square Vision Panel)
Kitchen, Laundry, Housekeeping
Single Door, Double Action, FDKS, Deadlock
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm |
| Core Width: | 54 mm |
| Structural Opening Width: | 1005 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
| Quantity | Component | Fitted |
|---|---|---|
| 1 | Double Action Floor Spring Set | Yes |
| 1 | Pull Handle | No |
| 1 | Push Plates | No |
| 2 | Kick Plates | Yes |
| 2 | FDKS Sign | Fr Only |
| 1 | Deadlock | Yes |
| 1 | Cylinder | No |
Doorset 26-PH (Port Hole)
Kitchen, Laundry, Housekeeping
Doorset 26-PH (Port Hole)
Kitchen, Laundry, Housekeeping
Double Door, Double Action, FDKS, Porthole Vision Panel
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm + 926 mm |
| Core Width: | 54 mm |
| Structural Opening Width: | 1934 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 21
| Quantity | Component | Fitted |
|---|---|---|
| 2 | Double Action Floor Spring Set | Yes |
| 2 | Pull Handles | No |
| 2 | Push Plates | No |
| 4 | Kick Plates | Yes |
| 2 | FDKS Sign | Fr Only |
| 1 | Deadlock | Yes |
| 1 | Cylinder | No |
| 1 | Escutcheon | Yes |
Doorset 26-SV (Square Vision Panel
Kitchen, Laundry, Housekeeping
Doorset 26-SV (Square Vision Panel
Kitchen, Laundry, Housekeeping
Double Door, FDKS, Deadlock, Double Action, Square Vision Panel
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm + 926 mm |
| Core Width: | 54 mm |
| Structural Opening Width: | 1934 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 23
| Quantity | Component | Fitted |
|---|---|---|
| 2 | Double Action Floor Spring Set | Yes |
| 2 | Pull Handle | No |
| 2 | Push Plate | No |
| 4 | Kick Plate | Yes |
| 2 | FDKS Sign | Fr Only |
| 1 | Deadlock | Yes |
| 1 | Double Action Keep | Yes |
| 2 | Flush Bolt | Yes |
| 1 | Easy Clean Floor Socket | No |
| 1 | Cylinder | No |
| 1 | Escutcheon | Yes |
Doorset 27
Store Room, Cupboard, Linen
Doorset 27
Store Room, Cupboard, Linen
Single Door, FDKL, Cylinder Pull, Deadlock
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1005 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 25
| Quantity | Component | Fitted |
|---|---|---|
| 3 | Hinges | Yes |
| 1 | Deadlock | Yes |
| 1 | Cylinder | No |
| 1 | Cylinder Pull | Yes |
| 1 | Escutcheon | Yes |
| 1 | FDKL Sign | Fr Only |
| 1 | Kick Plate | Yes |
Doorset 28
Store Room, Cupboard, Linen
Doorset 28
Store Room, Cupboard, Linen
Double Door, Lever Handle, FDKL, Sashlock
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm + 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1934 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 24
| Quantity | Component | Fitted |
|---|---|---|
| 6 | Hinges | Yes |
| 1 | Sashlock | Yes |
| 1 | Cylinder | Yes |
| 2 | Escutcheon | Yes |
| 1 | Lever Handle Set | No |
| 2 | FDKL Sign | Fr Only |
| 2 | Flush Bolt | Yes |
| 1 | Easy Clean Floor Socket | No |
Doorset 29
Store Room, Cupboard, Linen
Doorset 29
Store Room, Cupboard, Linen
Double door, Push/Pull, FDKL, Deadlock
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm + 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1934 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 30
| Quantity | Component | Fitted |
|---|---|---|
| 6 | Hinges | Yes |
| 1 | Deadlock | Yes |
| 1 | Cylinder | No |
| 2 | Escutcheon | Yes |
| 2 | Pull Handle | No |
| 4 | FDKL Sign | Fr Only |
| 2 | Flush Bolt | Yes |
| 1 | Easy Clean Floor Socket | No |
| 2 | Push Plate | No |
Doorset 29-CP (Cylinder Pull)
Store Room, Cupboard, Linen
Doorset 29-CP (Cylinder Pull)
Store Room, Cupboard, Linen
Double Door, Cylinder Pull, FDKL, Deadlock
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm + 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1934 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 26
| Quantity | Component | Fitted |
|---|---|---|
| 6 | Hinges | Yes |
| 1 | Deadlock | Yes |
| 1 | Cylinder | No |
| 1 | Cylinder Pull | Yes |
| 1 | Escutcheon | Yes |
| 2 | FDKL Sign | Fr Only |
| 2 | Kick Plate | Yes |
| 1 | Easy Clean Floor Socket | No |
| 2 | Flush Bolts | Yes |
Doorset 30
FOH, BOH
Doorset 30
FOH, BOH
Single Door, Lever Handle, FDKS, Sashlock
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1005 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 28
| Quantity | Component | Fitted |
|---|---|---|
| 3 | Hinges | Yes |
| 1 | Closer | No |
| 1 | Sashlock | Yes |
| 1 | Lever Handle Set | No |
| 1 | Cylinder | No |
| 2 | Escutcheon | Yes |
| 2 | FDKS Sign | Fr Only |
| 1 | Kick Plate | Yes |
Doorset 31
FOH, BOH
Doorset 31
FOH, BOH
Single Door, Lever Handle, FDKS, Sashlock
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1005 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 28
| Quantity | Component | Fitted |
|---|---|---|
| 3 | Hinges | Yes |
| 1 | Closer | No |
| 1 | Sashlock | Yes |
| 1 | Lever Handle | No |
| 1 | Cylinder | No |
| 2 | Escutcheon | Yes |
| 2 | FDKS Sign | Fr Only |
| 1 | Kick Plate | Yes |
Doorset 31-NL (Nightlatch)
FOH, BOH
Doorset 31-NL (Nightlatch)
FOH, BOH
Single Door, Lever Handle, FDKL, Nightlatch
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1005 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 35
| Quantity | Component | Fitted |
|---|---|---|
| 3 | Hinges | Yes |
| 1 | Closer | No |
| 1 | Sashlock | Yes |
| 1 | Nightlatch | Yes |
| 1 | Lever Handle Set | No |
| 1 | Cylinder | Yes |
| 2 | Escutcheon | Yes |
| 2 | FDKS Sign | Fr Only |
| 1 | Kick Plate | Yes |
| 1 | Half Spindle | No |
Doorset 31-PP (Push/Pull)
FOH, BOH
Doorset 31-PP (Push/Pull)
FOH, BOH
Single Door, Push/Pull, FDKS
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1005 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 27
| Quantity | Component | Fitted |
|---|---|---|
| 3 | Hinges | Yes |
| 1 | Closer | No |
| 1 | Deadlock | Yes |
| 2 | FDKS Sign | Fr Only |
| 2 | Kick Plate | Yes |
| 1 | Push Plate | Yes |
| 1 | Pull Handle | No |
| 1 | Escutcheon | Yes |
Doorset 32
FOH, BOH
Doorset 32
FOH, BOH
Unequal Double Door, Lever Handle, FDKL, Sashlock
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm + 463 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1471 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
| Quantity | Component | Fitted |
|---|---|---|
| 6 | Hinges | Yes |
| 1 | Closer | Yes |
| 1 | Sashlock | Yes |
| 1 | Lever Handle Set | Yes |
| 1 | Cylinder | Yes |
| 2 | Escutcheon | Yes |
| 2 | FDKS Sign | Yes |
| 2 | Flush Bolt | Yes |
| 1 | Easy Clean Socket | Yes |
| 2 | Kick Plates | Yes |
Doorset 33
FOH, BOH
Doorset 33
FOH, BOH
Double Door, Cylinder Pull, FDKL, Deadlock
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm + 926M mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1934 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2105 mm |
Ironmongery Items
Pack 26
| Quantity | Component | Fitted |
|---|---|---|
| 6 | Hinges | Yes |
| 1 | Deadlock | Yes |
| 1 | Cylinder | No |
| 1 | Cylinder Pull | Yes |
| 2 | FDKL Sign | Fr Only |
| 2 | Kick Plate | Yes |
| 1 | Easy Clean Floor Socket | No |
| 2 | Flush Bolts | Yes |
Pocket Door Configurations 1-4
Sliding Pocket Door, Suite, Bathroom, Restaurant, Conference
Pocket Door Configurations 1-4
Sliding Pocket Door, Suite, Bathroom, Restaurant, Conference
Portman Pack 1 *Does not open flush with wall (Circa 100mm protruding), Non-Locking
Portman Pack 2 *Opens flush with wall, Non-Locking
Portman Pack 3 *Does not open flush with wall (Circa 100mm protruding), Locking
Portman Pack 4 *Opens flush with wall, Locking
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1832 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2137 mm |
Ironmongery Items
Pack 1
| Quantity | Component | Fitted |
|---|---|---|
| 1 | Pocket Door System | No |
| 1 | Flush Pull Kit | No |
Pack 2
| Quantity | Component | Fitted |
|---|---|---|
| 1 | Pocket Doors System | No |
| 1 | Flush Pull Kit | No |
| 1 | Finger Pull | No |
Pack 3
| Quantity | Component | Fitted |
|---|---|---|
| 1 | Pocket Door System | No |
| 1 | Turn and Release Flush Pull Kit | No |
| 1 | Sliding Door Lock and Keep | Yes |
Pack 4
| Quantity | Component | Fitted |
|---|---|---|
| 1 | Pocket Door System | No |
| 1 | Turn and Release Flush Pull Kit | No |
| 1 | Sliding Door Lock and Keep | Yes |
| 1 | Finger Pull | No |
Pocket Door Configurations 5-8
Sliding Pocket Door, Suite, Bathroom, Restaurant, Conference
Pocket Door Configurations 5-8
Sliding Pocket Door, Suite, Bathroom, Restaurant, Conference
Portman Pack 1 *Does not open flush with wall (Circa 100mm protruding), Non-Locking, Double Door
Portman Pack 2 *Opens flush with wall, Non-Locking, Double Door
Portman Pack 3 *Does not open flush with wall (Circa 100mm protruding), Locking, Double Door
Portman Pack 4 *Opens flush with wall, Locking, Double Door
Technical Details
| Door Core: | Severecore ™ |
|---|---|
| Door Width (Recommended): | 926 mm + 926 mm |
| Core Width: | 44 mm |
| Structural Opening Width: | 1832 mm |
| Door Height: | 2052 mm |
| Structural Opening Height: | 2137 mm |
Ironmongery Items
Pack 5
| Quantity | Component | Fitted |
|---|---|---|
| 1 | Pocket Door System | No |
| 2 | Flush Pull Kit | No |
Pack 6
| Quantity | Component | Fitted |
|---|---|---|
| 1 | Pocket Door System | No |
| 2 | Flush Pull Kit | No |
| 2 | Finger Pull | No |
Pack 7
| Quantity | Component | Fitted |
|---|---|---|
| 1 | Pocket Door System | No |
| 1 | Turn and Release Flush Pull Kit | No |
| 1 | Sliding Door Lock and Keep | Yes |
| 2 | Finger Pull | No |
Pack 8
| Quantity | Component | Fitted |
|---|---|---|
| 1 | Pocket Door System | Yes |
| 1 | Turn and Release Flush Pull Kit | Yes |
| 1 | Sliding Door Lock and Keep | Yes |
| 2 | Finger Pull | Yes |
| 2 | Flush Pull Kit | Yes |
2 : Screens
Screens and fanlights provide transfer of natural light in internal spaces.
Side Screen (SS01)
Technical Details
| Maximum screen width | 900mm |
|---|---|
| Safety Rating | Class B |
Side screen & Fan light (SSFL01)
Technical Details
| Max screen width | 900mm |
|---|---|
| Safety rating | C (fanlight) & B (side screen) |
3 : Frames & Architraves
Standard frame and architrave details to suit most common wall types.
Standard
| Standard architrave | 44 x 18 mm x 3mm radiused edges |
|---|
Extended
| Extended | 60 mm wide |
|---|
Flush detail
| Flush frame | 10mm x 10mm shadow gaps |
|---|
Lining with planted door stops (LNG)
Our most popular frame type, suitable for most projects.
| Min. Wall Depth | 90mm |
|---|---|
| Max. Wall Depth | 156 mm (FD60) |
| Fire Rating | NFR, FD30, FD60 |
Split lining (SFR)
Most suitable for accommodatingg varying wall depths
| Min. Wall Depth | 156 mm |
|---|---|
| Max. Wall Depth | 350 mm |
| Fire Rating | NFR, FD30, FD60 |
Lining with Extension & Planted Stops (LLE)
Suitable for refurbishment projects
| Min. Wall Depth | 125 mm |
|---|---|
| Fire rating | NFR, FD30, FD60 |
Double Swing (DBS)
Double swing frame mainly intended for emergency release situations such as disabled bathrooms.
| Min, Wall Depth | 90mm |
|---|---|
| Max. Wall Depth | 200mm |
| Fire Rating | NFR, FD30, FD60 |
Bi-Fold (BIF)
Bi-folding frame style featuring a custom track in the head of the frame. Intended for corridors with restricted width.
| Min. Wall Depth | 90mm |
|---|---|
| Max. Wall Depth | 200mm |
| Fire Rating | NFR |
Interconnecting
Pair of back to back doors connecting two guest rooms.
This is our standard interconnecting offering, we understand that hotels have their own specific requirements and we will work with you to accommodate this.
| Fire Rating | NFR, FD30, FD60 |
|---|
4 : Vision Panel Styling
According to BS 8300:2009 Minimum zone of visibility should be between 500 mm and 1500 mm above floor level, with maximum interruption of 350 mm vertically within the zone. (This area is shown within the dashed line). Vision panels allow persons to view what is on the other side of the door and are an important safety feature, vital in preventing injury resulting from collision with opening doors.
5 : Facings & Finishes
WOOD VENEER
Real wood veneers offer sustainability, durability, and a natural aesthetic.
- Natural aesthetic
- Range of colours & grains
- FSC® certified
- Available with ‘Hygienilac’ lacquer
- Crown or quarter cut
Benefits
Due to the nature of wood, photography may vary and be inaccurate in depicting the uniqueness of veneer and stained veneer. We are happy to provide our customers with samples of our veneers and stained veneers.
SAMPLE SERVICE
We are constantly developing new stains and can only represent a small sample of our capabilities in this brochure. We can also offer pre-dyed veneer. If you require more information contact our sales team who will be able to talk you through additional options.
MATCHING SERVICE
We appreciate that you may have a specific veneer or stained veneer in mind for your doors, perhaps on a piece of furniture. If you can supply us with a sample we may be able to match it for you. We have successfully done this on many occasions, ensuring our customers achieve the finish they desire.
Veneers
Woodrow Oak
Crown Cut
Dark Walnut
Crown Cut
Ebony Ash
Crown Cut
Ebony Oak
Crown Cut
Creme
Crown Cut
Linen
Crown Cut
Walnut Burr
Special
A.B Walnut
Crown Cut
6 : Lock Types
Deadlock
Single cylinder bolt operated by keys and/ or thumb turns.
Sashlock
Lever handles operating a latch bolt, keys and or thumb turns operate a deadbolt.
Escape Lock
Allows for a egress in a single operation in case of an emergency, even when the door is locked.
Nightlatch
Latch bolt will automatically lock when the door closes.
Bathroom lock Types
Lever handles operate a latch bolt, thumb turn on bathroom side operates a deadbolt with an occupancy indicator on the external side.
Fire protection
For all fire rated doors, lock-cases and keeps will be clad in fire retardant intumescent
Cylinders
Lock cylinders are delivered individually engraved to ensure they all find their intended door.
Hotel and Hospitality Range Gallery
